Output Channels:2 channels
Frequency Range:DC to 20 MHz
Amplitude Range:1 mVpp to 10 Vpp
Resolution:14 bits
Waveform Types:Sine, Square, Triangle, Pulse, Arbitrary
Sampling Rate:100 MSa/s
Phase Shift:+/- 10 degrees
Memory Depth:16 kpoints
Interface:USB, GPIB
The Tektronix 5440 Digital Storage Oscilloscope stands out with its robust performance designed for demanding applications. With a bandwidth of 500 MHz and a sample rate of 1 GS/s, this oscilloscope ensures accurate and detailed signal analysis. Featuring 4 channels, it provides versatile testing capabilities, making it suitable for a wide range of industries including automotive, telecommunications, and electronics manufacturing. The high-resolution 7-inch TFT LCD display offers clear and detailed visualization of waveforms. With a maximum input voltage of ±30V and an input impedance of 1 MΩ, the oscilloscope can handle a variety of signals without distortion. Additionally, it comes equipped with a large memory depth of 14 Mpts for extended recording periods. The oscilloscope supports multiple trigger modes, including edge, pulse, video, and pattern, providing flexibility in signal analysis. Connectivity options include USB Host, USB Device, and Ethernet, allowing for seamless integration with other devices and networks.
