Siemens A5E00825001 IGBT MODULE – Power Electronics Solution

Technology Type:IGBT

Module Size:Standard

Operating Temperature Range:-40°C to +125°C

Max Current Rating:2500A

Max Voltage Rating:1200V

Switching Frequency:Up to 20kHz

Efficiency Rating:98%

Cooling Method:Thermal Conduction

Input/Output Connections:4-pole terminal block

Certifications:UL, CE, ISO 9001

    The Siemens A5E00825001 IGBT Module is engineered to deliver unparalleled performance in demanding industrial environments. It leverages the latest semiconductor technology to ensure high-efficiency power conversion, critical for modern manufacturing systems.

    This module is meticulously designed with an optimal balance between size, weight, and cooling efficiency, making it highly adaptable for various applications. Its robust construction ensures reliability under extreme conditions, reducing downtime and maintenance costs.

    Featuring a wide operating temperature range from -40°C to +125°C, the A5E00825001 can withstand harsh industrial settings without compromising performance. Its 1200V voltage rating and 3200A current handling capability make it suitable for high-power applications.

    Equipped with advanced insulation class F, this IGBT module offers enhanced safety margins and extended operational life. The water-cooled design optimizes heat dissipation, ensuring stable operation even under high-load conditions.

    With its versatile specifications and robust performance, the Siemens A5E00825001 IGBT Module is an ideal choice for power-intensive industries seeking to enhance their efficiency and sustainability.
