Product Type:Other
Product ID:UK5-HESI
Phoenix Type Designation:Other
Fuse Type:Glass / Ceramics / Others
Number of Positions:1
Connection Method:Screw Connection
Cross Section:0.2 mm² – 4 mm²
AWG:24 – 12
Nominal Current:32 A
Nominal Voltage:500 V
Width:8.2 mm
Mounting Type:NS 35/7.5, NS 35/15, NS 32
Color:Black
Number of Levels:1
Number of Connections:2
Nominal Cross Section:4 mm²
Color (Double-Level):Gray
Rated Surge Voltage:6 kV
Maximum Load Current:32 A
Width (Double-Level):6.2 mm
Length (Double-Level):56 mm
The Phoenix UK5-HESI Fuse Modular Terminal Block is designed for high reliability and easy installation in industrial environments.
Featuring a screw connection method, this terminal block ensures secure power distribution with a wide range of cross-section compatibility.
With a maximum nominal current of 6.3 A and a nominal voltage of 800 V, it is ideal for applications requiring robust electrical connections.
The compact design, measuring 8.2 mm in width, allows for efficient space utilization in complex wiring scenarios.
The inclusion of various fuse types and a choice of mounting options caters to diverse installation needs, enhancing its versatility across different industries.
