Control Power nominal:50-300 VDC / 40-265 VAC
Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz
Dimensions:approx. 12 in H x 5 in W x 8 in L
Ground Current Input Frequency:20 to 100 Hz
Insulation Class:Class I
Phase Current Input Conversion:True RMS, 1.04 ms/sample
Weight:approx. 4.5 kg
Communications:non-isolated RS232 port, RS485 port
Differential Switch Time Delay:<200 ms
Event Record Triggers:power fail, alarms, self test, inhibit, trip, waveform capture
Operating Range:-40°C (-40°F) to +60°C (140°F)
Storage Range:-40°C (-40°F) to +80°C (176°F)
The GE 369-HI-0-M-0-0-0 is a robust and reliable motor management relay that offers comprehensive protection and monitoring for industrial motors and equipment.
With advanced features like true RMS phase current input conversion, metering capabilities, and versatile communication options, this relay ensures optimal performance and reduced downtime.
The device is equipped with a differential switch time delay of less than 200 ms, enabling swift response to critical events.
Additionally, the 369-HI-0-M-0-0 supports waveform capture, event reports, and data logging, which significantly lower maintenance costs and minimize troubleshooting time.
Designed for durability, this relay can operate within a wide temperature range from -40°C to +60°C, making it suitable for harsh industrial environments.
The compact design and lightweight construction make installation and maintenance effortless.
