AB 1746-NI4B Analog Input Module

Number of Channels:4

High Resolution:Yes

Common Mode Voltage Range:-20 To 20 V

Absolute Input Voltage:Plus/Minus 7.5 VDC Or 7.5 VAC RMS (Maximum)

Input Range:-10 To 10 VDC – 1 LSB

Absolute Input Current:-30 To 30 MA (Maximum)

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Current Rating:Backplane Current Draw: 35 MA At 5 V, 85 MA At 24 V

Isolation:Backplane: 500 VDC, Enclosure: Open Type

    Experience unparalleled precision with the Allen Bradley 1746-NI4B Analog Input Module, designed to enhance the efficiency and reliability of your industrial automation systems. This high-resolution module supports up to four channels, providing accurate readings essential for critical system monitoring.

    The module boasts an extensive input voltage range from -20 to +20 VDC, ensuring compatibility with a wide array of industrial setups. Its ability to handle currents from -30 to +30 mA ensures robust performance under varying conditions.

    Featuring overvoltage protection of 7.5 VAC RMS, the 1746-NI4B is engineered to withstand unexpected electrical fluctuations, safeguarding your system from potential damage. Its voltage rating exceeds 10 VDC, guaranteeing durability and longevity.

    With isolation capabilities of 500 VDC backplane and open type enclosure, this module offers superior protection against electrical interference, ensuring stable operation in even the most challenging environments.

    Effortlessly integrate the Allen Bradley 1746-NI4B Analog Input Module into your existing setup with its versatile current ratings, enabling seamless connectivity at either 5 V or 24 V. This makes it an ideal choice for a wide range of applications, from manufacturing lines to complex industrial systems.
